Description
Edelbrock #8010 water pump for 1955-68 SBC passenger cars,
1969-70 350 c.i.d, Corvettes and 1955-72 Light duty Trucks.
Edelbrock #8010 water pump for 1955-68 SBC passenger cars, 1969-70 350 c.i.d, Corvettes and 1955-72 Light duty Trucks. Provides maximum cooling form the street and the race track. Water pump provide maximum flow, maximum pressure and equal distribution to both sides of the block with 1%.
Thermostat And Housing Included No
Thermostat And Housing Included No
Mounting Hole Quantity 4
Housing Material Aluminum
Impeller Material Powdered Metal
Installation Warnings Yes
Hub Hole Quantity 6
Fan Clutch Included No
Impeller Vane Quantity 6
Includes Back Housing Yes
Related Cooling Fan Components No
Casting Number 8810
Warranty 12 Months
Hub Height 5.625 in
Impeller Rotation Standard
Outlet Quantity 1
Pulley Included No
Water Pump Drive Type V-Belt
Installation Notes
1969-'76 vehicles (original pump casting #3853692) require the included spacer to be placed between the pump and the alternator bracket; Some applications (original pump casting #364790) require power steering bracket spacer (included); Some vehicles (original pump casting #6263701) require a through hole instead of the threaded hole for the power steering. If this is the case, drill out the threads with a 3/8" drill bit; Check closely for any interference with drive belts; some filing for clearance may be necessary with some applications; Installation is the same as for original equipment water pumps. Consult service manual for specific procedures, if necessary; CAUTION: Be sure that fan bolts don't protrude through the hub so far that they hit the water pump housing; NOTE: Removal of backing plate is not recommended, as there are no user serviceable parts in the water pump. If backing plate is removed, use no sealer on O-ring equipped models, and use conventional gasket sealer (not RTV silicone) on gasketed models.
Specifications
Chevrolet:Corvette:350 (5.7L);Chevrolet:Small-Block:262 (4.3L)-400 (6.6L);Chevrolet:Small-Block Light Duty Trucks:262 (4.3L)-400 (6.6L)
SKU | ED88100 |
Barcode # | 00085347088102 |
Brand | Edelbrock |
