Description
The Edelbrock ED60675 Performer RPM cylinder heads are designed for 1968-87 429/460 BB Ford engines. The Edelbrock 60675 Performer RPM heads are perfect for street performance, daily drivers and muscle cars where more performance is needed.
75cc Chambers + 292cc Runners + Hydraulic Roller
SOLD AS A SINGLE CYLINDER HEAD
The Edelbrock #60675 Performer RPM cylinder head is designed for 1968-87 429/460 Big-Block Ford applications. The Edelbrock #60675 Performer RPM head is perfect for street performance, daily drivers, street rods and muscle cars where seat-of-the-pants performance is needed. This cylinder head delivers great throttle response and power from 1500 to 6500 rpm. They also feature the highest quality intake and exhaust valves and valve springs. For use on pre-pollution controlled vehicles only.
Combustion Chamber Volume (cc): 75
Intake Runner Volume (cc): 292cc
Exhaust Runner Volume (cc): 100cc
Cylinder Head Style: Assembled
Cylinder Head Material: Cast aluminum
Intake Valve Diameter (in.): 2.190 in.
Intake Port Location: Standard
Exhaust Port Location: Standard
Exhaust Valve Diameter (in.): 1.760 in.
Maximum Valve Lift (in.): 0.730 in.
Camshaft Style: Hydraulic roller
Outside Diameter of Outer Spring (in.): 1.580 in.
Number of Springs Per Valve: Dual
Lock Style: 7 degrees
Valve Stem Seals Included: Yes
Valve Stem Seal Style: Positive stop
Rocker Arm Studs Included: Yes
Rocker Arm Nut Thread Size: 7/16 in.-20
Guideplates Included: Yes
Guideplate Pushrod Size: 3/8 in.
Valve Cover Mounting Style: Perimeter bolt
Accessory Bolt Holes Drilled: Yes
Intake Valve Angle: 18.7
Exhaust Valve Angle: 16.7
Valve Guides Included: Yes
Valve Guide Material: Manganese bronze
Valve Seats Machined: Yes
Valve Seat Machine Style: 3-angle
Valve Seat Material: Ductile iron
Heat Crossover: No
Quantity: Sold individually.
Notes: Cylinder heads have no crossover passage or AIR passages.
Specifications
Ford:Big-Block:429 (7.0L )/460 (7.5L)
SKU | ED60675 |
Barcode # | 00085347606757 |
Brand | Edelbrock |
